PV32 is a hydraulic load sensing valve designed to give maximum flexibility. From a simple load sensing directional valve, to an advanced electrically controlled load-independent proportional valve. PV32 modular system makes it possible to build up a valve group to meet requirements precisely. The compact external dimensions of the valve remain unchanged whatever combination is specified.
FEATURES
◼ Load-independent flow control:
- Oil flow to an individual function is independent of the load pressure of this function
- Oil flow to one function is independent of the load pressure of other functions
◼ Good regulation characteristics
◼ Energy-saving
◼ Up to 12 basic modules per valve group
◼ Several types of connection threads
◼ Low weight
◼ Compact design and installation
TECHNICAL DATA
| Max. Pressure | P/A/B continuous | 350bar |
| With PVSI ending section，P intermittent | 400bar | |
| A/B intermittent | 420bar | |
| T (Static/Dynamic) | 25 bar/40 bar | |
| Rated Flow | P (PVP/PVPVM) | 140/230 L/min |
| A/B，with pressure compensator | 100 L/min | |
| A/B，without pressure compensator | 125 L/min | |
| Spool Stroke (standard) | ±7 mm | |
| Spool Stroke (float position) | Proportional range | ±4.8 mm |
| Float position | ±8 mm | |
| Dead Band (Spool=FC) | Standard | ±1.5 mm |
| Linear Characteristic | ±0.8 mm | |
Max. Internal Leakage | A/B→T with PVLP | 20 mL/min |
| A/B→T without PVLP | 25 mL/min | |
| Inlet Temperature | Recommended temperature | 30~60 ℃ |
| Min. temperature | ~30 ℃ | |
| Max. temperature | +90 ℃ | |
| Ambient Temperature | -30~60 ℃ | |
| Viscosity | Operating range | 12~75 mm²/s |
| Min. viscosity | 4 mm²/s | |
| Max. viscosity | 460 mm²/s | |
| Filtration (ISO4406) | 23/19/16 | |
| Consumption in pilot oil pressure reduction valve | 0.5 L/min | |
Application example
PVP Side inlet modular
PVPVM Middle inlet modular
DIMENSIONS
PVB No. | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 |
M [mm] | 82 | 130 | 178 | 226 | 274 | 322 | 370 | 418 | 466 | 514 | 562 | 610 |
L [mm] | 141 | 190 | 238 | 287 | 335 | 384 | 432 | 481 | 529 | 578 | 626 | 675 |
Weight [kg] | 8.5 | 11.8 | 14.7 | 17.9 | 20.9 | 24.2 | 27.2 | 31.2 | 33.2 | 36.6 | 39.8 | 42.6 |
